Điện áp |
690V AC/DC |
Dòng điện |
32A |
Dòng cắt |
200kA |
Kích thước |
1 cực, 17.5mm x 76.5mm |
Mã sản phẩm
|
CMC101 |
Partno |
P1062705 |
Series |
CMC |
Chủng loại |
Đế cầu chì 10x38mm |
Tiêu chuẩn |
IEC 60269-2 and IEC 60947-3 Compliance
RoHS, Reach compliant
Marine certificates
|
Ứng dụng |
Sử dụng cho cầu chì 10x38mm dòng aM, gG, Protistor®
|
DF101 (SCHNEIDER)
Short Description: modular fuse holder, IEC, 1P, 10x38, DIN rail mounting, IP20
ROHS Compliant: Yes
Short Circuit Current Rating (SCCR): 200 kA
Fuse Size: 10x38
Design Details: CMC10 single pole
Number of Poles: 1-Pole
Torque Rating: 17.7 lb-in
Rated Impulse Withstand Voltage: 6
Rated Insulation Voltage: 1000 V
Conventional Free Air thermal Current With Fuse-Links Ith: 32 A
Max Power dissipation of Fuse Links Pn: 3 W
Installation Mounting: DIN rail acc. EN 60715
Comments: Wiring tool : PZ2 or flat 5.5x1mm screw drivers recommended (max. diameter 6mm)
Product Weight: 0.099 lb
Product Width: 0.69 in
Product Length: 2.41 in
Product Height: 3.12 in
Sell Pack Quantity: 12 EACH
*Modulostar® compact fuse-holders for 10.3x38.1 fuse-links, without indicator
Catalog number |
Number of poles/phases |
CMC101 |
1 |
CMC101N |
1 + N |
CMC102 |
2 |
CMC103 |
3 |
CMC103N |
3 + N |
CMC104 |
4 |
CMC810N |
N |
